This Rear Mount system allows you to mount one of several different items on the back of your truck camper (see complete list below) without drilling holes into the sides of the camper. It provides a super solid mounting location. Whether you want to mount a Roto Pax container, a jerry can, a propane tank or a Joolca hot water heater, this Rear Mount has you covered! Proudly designed and made in the USA!
One set includes parts for a single mount. The mount is reversible and can be installed on the driver or passenger side. Buy two Rear Mounts to mount something on both sides. A set consists of a laser cut stainless steel plate and bracket and high quality hardware along with comprehensive installation instructions.
These Rear Mounts are designed with the Reico Titan and Atwood bolt spacing. See bolt spacing drawing in the pictures to confirm that's what you have. The Rear Mount is adjustable and is configurable to work with the majority of truck campers that have the Reico Titan Jacks. The system is designed to work with Frank Design Quick Jack Releases or on it's own with or without jacks.
Max weight rating per Rear Mount is 65 lbs.
In order to attach your item of choice to the Rear Mount you will need to purchase the product's manufacturer's mounting bracket. Below is a complete list of mounts required for what you want to put on the back of your camper. These items are not included with the Frank Design Rear Mount and must be purchased separately.
-To mount a 1 to 3 gallon RotoPax container, you will need a RotoPax STANDARD, DLX, or LOX mounting kit
-To mount a Joolca HOTTAP V2 Water Heater, you will need a Joolca Quick-Release HOTTAP Bracket
-To mount a Wavian 5 Gal/20L Jerry Can, you will need a Wavian Gas Can Holder (Front Loading only) P/N: 4286
-To mount any of the following 9” dia Propane Tanks, you will need Power Tank bracket P/N: BKT-2286
11 lb. Worthington 2.6 gal. (P/N: 28116)
10 lb. Manchester 2.5 gal. (P/N: 10228.4)
10 lb. Ignik 2.5 gal
4.25 lb. Worthington 1 gal. (P/N: 281149)
10 lb. Flame King 2.5 gal. (P/N: YSN010)
Note: The Rear Mount does require drilling two small holes for screws in the underside of the overhang on the side of the camper.
